IMA-S2000-48-YV

Enclosed

IMA 系列

IMA-S2000-48-YV

输出电压

48V

输出功率

2000W

输出电流

41.6A

输入电压范围

80 - 275 Vac

尺寸 (L x W x H)

309.6 x 127 x 40.6 mm

12.19” x 5.00” x 1.60”

重量

2 kg (4.41 lb)

亮点与特色

Safety approval for Medical (IEC 60601-1-2 and 3rd+A1 edition CB report) TUV EN60601-1:2006
CAN/CSA-C22.2 NO.60601-1 + ANSI/AAMI, ES 60601-1, 3000m altidude, 100-240Vac only
Industrial (IEC 62368) and IT IEC60950-1 CB report, IEC62368-1 CB report, TUV EN62368-1, UL62368-1 and CAN/CSA C22.2 No. 62368-1
3000 Watt peak power (up to 5s)
Standby power < 2 Watt
Wide operating input voltage range: 80 Vac to 275 Vac or 120 Vdc to 300 Vdc
Wide adjustable output voltage range (+/- 20%)
Standby output 5 Vdc / 2 A
High efficiency: up to 94%
Size: 309.6 x 127 x 40.6 mm (12.2 x 5 x 1.6 in) (1U design)
Low acoustic noise level of less than 39 dB(A), variable speed fan control
Active current sharing
2 × MOPP and BF appliances
PMBus™ compatible for control, programming and monitoring
500,000 hour MTBF
Optional conformal coating
3 years warranty

Optional Models

Model	Description
IMA-C2000-48-YV	Conformal coated version

应用领域

Enclosed

IMA 系列

IMA-S2000-48-YV

亮点与特色

Safety approval for Medical (IEC 60601-1-2 and 3rd+A1 edition CB report) TUV EN60601-1:2006
CAN/CSA-C22.2 NO.60601-1 + ANSI/AAMI, ES 60601-1, 3000m altidude, 100-240Vac only
Industrial (IEC 62368) and IT IEC60950-1 CB report, IEC62368-1 CB report, TUV EN62368-1, UL62368-1 and CAN/CSA C22.2 No. 62368-1
3000 Watt peak power (up to 5s)
Standby power < 2 Watt
Wide operating input voltage range: 80 Vac to 275 Vac or 120 Vdc to 300 Vdc
Wide adjustable output voltage range (+/- 20%)
Standby output 5 Vdc / 2 A
High efficiency: up to 94%
Size: 309.6 x 127 x 40.6 mm (12.2 x 5 x 1.6 in) (1U design)
Low acoustic noise level of less than 39 dB(A), variable speed fan control
Active current sharing
2 × MOPP and BF appliances
PMBus™ compatible for control, programming and monitoring
500,000 hour MTBF
Optional conformal coating
3 years warranty

输出电压

48V

输出功率

2000W

输出电流

41.6A

输入电压范围

80 - 275 Vac

尺寸

309.6 x 127 x 40.6 mm

12.19” x 5.00” x 1.60”

重量

2 kg (4.41 lb)

应用领域

Optional Models

Model	Description
IMA-C2000-48-YV	Conformal coated version

资源下载

Datasheet

Uploaded on 24-Jan-2024


Uploaded on 15-Feb-2024

.DXF

Uploaded on 24-Jan-2024

.STP

Uploaded on 24-Jan-2024

App Notes

Uploaded on 24-Jan-2024

认证

Uploaded on 24-Jan-2024

Uploaded on 14-Feb-2024

CQC

Uploaded on 24-Jan-2024

Uploaded on 14-Feb-2024

REACH

Uploaded on 14-Feb-2024

RoHS

Uploaded on 14-Feb-2024

UKCA

Uploaded on 14-Feb-2024

Uploaded on 24-Jan-2024

GUI Software

Tech Specs

输出电流

41.6A

输出电压

48V

输出电压范围

48Vdc

输出电压调整范围

38.4 V – 57.6 V

输出功率

2000W

保持时间

20 ms

电容性负载启动

10,000 μF

残留波纹/PARD (20MHz)

< 480 mV

升压时间

< 200 ms

额定输入电压

100 - 240 Vac

输入电压范围

80 - 275 Vac

额定输入频率

50 - 60 Hz

输入频率范围

47-63Hz

直流输入电压范围

120 - 300 Vdc

输入电流

17.2 A @ 80 Vac
12 A @ 120 Vdc

最大涌入电流

< 25 A

功率因数

> 0.97 (typical)

漏电流

AC Leakage current from Input to earth ground
AC Leakage current from Output to earth ground

底座 / 外壳上盖 -
指示灯 Green LED
冷却方式 2 fans with variable speed control
输入端 Block M4 x 3 pins
输出端 Block M5 x 2 pins
信号端 Connector x 14 pins
声压级（SPL） < 39 dB(A)
输入/输出端 -
信号 -
安装导轨 -
电线 -
保护结构 -
端子台 -
重量 2 kg (4.41 lb)	尺寸 309.6 x 127 x 40.6 mm 12.19” x 5.00” x 1.60”

运行温度

-20 °C to +70 °C (-4°F to +158 °F)

储存温度

-40 °C to +85 °C (-40 °F to +185 °F)

功率降级

When AC input voltage is < 110 Vac, the output power is reduced by 20 W per 1 V.

防震测试（非运行状态）

IEC 60068-2-27 compliant, 50 g, 11 ms, 3 shocks for each direction

振动测试（非运行状态）

IEC 60068-2-6 compliant, 2.09 Grms, 5 - 500 Hz, 20 minutes per side (3 planes)

运行高度

5000 m (54kPa)

污染程度

过压保护

YES, latch mode
58 V to 61 V

超负载/过电保护

3000 W for over 750 ms max
Standby 3.2 A max with Hiccup Mode (Non-Latching, Auto-Recovery)

过热保护

YES, auto recovery

短路保护

YES, auto recovery

MTBF

500,000 hours

预计最长使用寿命

10 years

Safety Certificate

IEC 62368 Edition 2:
IEC 62368-1 (2014) Edition 2
5000 m (16,400 ft) altitude, 120 V to 300 Vdc and 100 V to 240±10% Vac

IEC/EN 60950-1, Edition 2 and all national deviations:
UL 60950-1/CSA 22.2 No 60950-1, Edition 2; UL 62368-1
5000 m (16,400 ft) altitude, 120 V to 300 Vdc and 100 V to 240 ±10% Vac (UL File E135494)

IEC/EN 60601-1, Edition 3:
IEC 60601-1(2005), EN60601-1(2006)
ANSI/AAMI ES 60601-1(2005)
CAN/CSA C22.2 No. 60601-1 (2008); 3,000 m (9,800 ft) altitude, 100 V to 240 Vac ±10%

IEC 60601-1-2 Edition 4:
IEC 60601-1-2 (2014)

排放

EN 55032, EN 55032 and FCC, Class B

谐波电流排放

EN 61000-3-2, Class A

电压波动和闪变

EN 61000-3-3

ESD 抗扰度

EN 61000-4-2, level 4, 8 kV contact, 15 kV air

辐射抗扰度

EN 61000-4-3, level 3, 12 V/m

EFT

EN 61000-4-4, level 4, ±2 kV

电涌

EN 61000-4-5, level 4, 1 kV DM, 2 kV CM

传导抗扰度

EN 61000-4-6, level 3, 10 Vrms

磁场

EN 61000-4-8, level 3, 10 A/m

电压骤降

EN 61000-4-11, 30%, 20 ms - R&D
EN 61000-4-11, 60%, 100 ms
EN 61000-4-11, 100%, 500 ms
EN 60601-1-2:2015 (4th edition), 30%, 500 ms
EN 60601-1-2:2015 (4th edition), 60%, 100 ms
EN 60601-1-2:2015 (4th edition), 100%, 20 ms
EN 60601-1-2:2015 (4th edition), 100%, 5000 ms
